Description
Get An Intelligent Relay Pack To Control The Power Sent To Individual Lighting Units – The CHAUVET Professional Synapse 4 Relay Pack
Synapse 4 functions as an intelligent relay pack to control the power sent to individual lighting units. Synapse 4 can de-power entire sections of an installation, which prolongs the lifespan of lighting fixtures and decreases overall power consumption, saving energy and money. Rack, truss or wall mountable, Synapse 4 also offers flexible options to control its four outputs: 1) via DMX; 2) upon sensing the loss of the DMX signal; 3) via an internal scheduler that can be used to specify that individual outputs be turned on/off. As an added convenience, a 4-port DMX opto-isolator allows users to easily branch their DMX universe in multiple directions and amplify the signal after a long cable run.
Controllable powerCON relay pack and DMX optically isolated splitter/amplifier
Compounds the savings of LED fixtures by completely removing power when not in use
Individually control all 4 relays via DMX, DMX sensing or internal scheduler for specific on/off times every day
Optically isolated 5-pin DMX splitter provides an easy hub for running DMX to multiple locations
Convenient mounting options; rack mount, wall mount or clamped to truss
SPECIFICATIONS
Construction/PhysicalL
Dimensions: 19 x 7.87 x 1.75 in (483 x 200 x 44.5 mm)
Weight: 6 lb (2.8 kg)
Exterior Color: Black
Rackmount: 1U
Connections
Power Connection: Edison (Local) plug to Neutrik powerCON
Power Input: Neutrik powerCON
Power Output: Neutrik powerCON
Data Connectors: 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
Control
Control Protocol: DMX
DMX Channels: 1 or 4
Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Main breaker size: 20 A, 250 V
Breaker size per output: 20A, 250 V
In The Box
Synapse 4
Neutrik powerCON power cord
Manufacturer: Chauvet Professional
Model: SYNAPSE4
SKU: I384650-N-0-WHXB
UPC: 781462214364
