Description
The MXR Bass Overdrive is an original design that delivers warm, tube-like overdrive. Along with standard Volume, Tone and Drive controls, this pedal features a Clean control so you can blend a pre-set EQ clean signal with the overdrive signal, resulting in sweet burly bass overdrive.
Description
- A unique overdrive circuitdesigned specifically for bass
- Separate clean and drivecontrols for tonal versatility
- 100% analog circuitry for richwarm tone
Power
The MXR Bass Overdrive is powered by one 9 volt battery (remove bottom plate to install), a 9 volt AC Adapter such as the Dunlop ECB003/ECB003EU or a power supply such as the DC Brick.
Directions
- Run a cable from your bass to the Bass Overdrive’s Input jack and run another cable from the Bass Overdrive’s Output to your amplifier.
- Set all controls to the 12 o’clock position.
- Turn the effect on by depressing the FOOTSWITCH.
- Rotate the CLEAN control clockwise to increase the blend of preset EQ clean signal or counterclockwise to decrease it.
- Rotate the VOLUME control clockwise to increase the overall volume of the effect or counterclockwise to decrease it.
- Rotate the TONE control clockwise for a brighter tone or counterclockwise for a darker sound.
- Rotate the DRIVE control clockwise to increase the amount of overdrive or counterclockwise to decrease it.
Specifications
- Input Impedance : 1 MΩ
- Output Impedance : <10 kΩ
- Signal to Noise* : >95 dB
- Current Draw : 19 mA
- Power Supply : 9 volts DC
Controls
- CLEAN knob blends in a tuned clean signal with the overdrive signal
- VOLUME knob controls the overall volume of the pedal
- TONE knob controls the color of the overdrive signal
- DRIVE knob controls the amount of overdrive
- FOOTSWITCH toggles effect on/by bass (white LED indicates on)
| CODE | MXR-M89-B |
|---|---|
| Brand | MXR |
| Weight | 0.700000 |
