Description
Capture A Whole New Dimension Of Immersive Sound With The Rode NT-SF1 Soundfield Ambisonic Microphone
SoundField invented the ambisonic microphone, revolutionizing 3D audio production. RODE revolutionized the microphone industry, using advanced manufacturing techniques to deliver broadcast-quality precision microphones at accessible prices. Now, for the first time, the magic of these two iconic brands has come together.
Based on a completely new capsule designed by RODE, the NT-SF1 offers extremely low noise and unprecedented smoothness and extension of frequency response. The ambisonic arrangement and tuning is drawn directly from high-end SoundField technology, ensuring the most accurate spatialization possible for the ultimate in 3D audio positioning.
Applications
The NT-SF1 is the perfect mic for a range of applications, from music recording through to capturing 3D soundscapes for VR applications. As productions increasingly require the use of surround or multi-channel spatial reproduction, the NT-SF1 should be part of every sound recordist’s arsenal.
The SoundField Story
The SoundField legend starts in 1978 in the UK, with the first commercial SoundField microphone launched based on the pioneering work of Michael Gerzon. SoundField is now a global leader in high-end ambisonic microphones, installed in many of the world’s most iconic venues. SoundField became part of the Freedman Group in 2016, paving the way for joint developments with RODE.
SPECIFICATIONS
Acoustic and Electrical
Acoustic Principle: Externally Biased Condenser
Active Electronics: JFET impedance converter with bipolar output buffer
Polar Pattern: Cardioid
Frequency Range: 20Hz – 20kHz
Output Impedance: 63Ω
Equivalent Noise (A-weighted): 17 dB SPL (as per IEC651)
Maximum SPL: 129 dB SPL
Sensitivity: -30.4 dB re. 1 Volt/Pascal (30mV @ 94dB SPL, 1kHz)
Power Requirements: 6.2mA @ 48V (Per Channel) Phantom Power
Frequency Response: 30 Hz – 20 kHz ±3dB // 20 Hz – 20 kHz ±4dB
Signal to Noise Ratio: 77 dB
Input SPL @ 1% THD: 129 dB SPL (1kHz @ 1% THD, 600Ω load)
Mechanical
Material: Brass
Color: Black
Weight: 286g
Dimensions (L x W x H): 45.7 x 192.3 x 45.7mm, diameter of body: 25.1mm
Packed Weight: 2960 (g)
Package Dimensions (L x W x H): 161 x 270 x 386mm
Manufacturer: Rode Microphones
Model: NT-SF1
SKU: I565256-N-0-WHXB
UPC: 698813005314
